RabbitMQ七种队列模式介绍与应用场景（通俗易懂）

Joe.Ye • 2023-04-02 • RabbitMQ

七种模式介绍与应用场景

简单模式（Hello World）

做最简单的事情，一个生产者对应一个消费者，RabbitMQ相当于一个消息代理，负责将A的消息转发给B
应用场景：将发送的电子邮件放到消息队列，然后邮件服务在队列中获取邮件并发送给收件人

工作队列模式（Work queues）

在多个消费者之间分配任务（竞争的消费者模式），一个生产者对应多个消费者，一般适用于执行资源密集型任务，单个消费者处理不过来，需要多个消费者进行处理
应用场景：一个订单的处理需要10s，有多个订单可以同时放到消息队列，然后让多个消费者同时处理，这样就是并行了，而不是单个消费者的串行情况

订阅模式（Publish/Subscribe）

一次向许多消费者发送消息，一个生产者发送的消息会被多个消费者获取，也就是将消息将广播到所有的消费者中。
应用场景：更新商品库存后需要通知多个缓存和多个数据库，这里的结构应该是：

一个fanout类型交换机扇出两个消息队列，分别为缓存消息队列、数据库消息队列
一个缓存消息队列对应着多个缓存消费者
一个数据库消息队列对应着多个数据库消费者

路由模式（Routing）

有选择地（Routing key）接收消息，发送消息到交换机并且要指定路由key ，消费者将队列绑定到交换机时需要指定路由key，仅消费指定路由key的消息
应用场景：如在商品库存中增加了1台iphone12，iphone12促销活动消费者指定routing key为iphone12，只有此促销活动会接收到消息，其它促销活动不关心也不会消费此routing key的消息

主题模式（Topics）

根据主题（Topics）来接收消息，将路由key和某模式进行匹配，此时队列需要绑定在一个模式上，#匹配一个词或多个词，*只匹配一个词
应用场景：同上，iphone促销活动可以接收主题为iphone的消息，如iphone12、iphone13等

远程过程调用（RPC）

如果我们需要在远程计算机上运行功能并等待结果就可以使用RPC，具体流程可以看图。
应用场景：需要等待接口返回数据，如订单支付

发布者确认（Publisher Confirms）

与发布者进行可靠的发布确认，发布者确认是RabbitMQ扩展，可以实现可靠的发布。在通道上启用发布者确认后，RabbitMQ将异步确认发送者发布的消息，这意味着它们已在服务器端处理
应用场景：对于消息可靠性要求较高，比如钱包扣款

代码演示

代码中没有对后面两种模式演示，有兴趣可以自己研究

<dependency>
    <groupId>com.rabbitmq</groupId>
    <artifactId>amqp-client</artifactId>
    <version>5.6.0</version>
</dependency>

简单模式

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Sender {

    private final static String QUEUE_NAME = "simple_queue";

    public static void main(String[] args) throws IOException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        // 声明队列
        // queue：队列名
        // durable：是否持久化
        // exclusive：是否排外  即只允许该channel访问该队列   一般等于true的话用于一个队列只能有一个消费者来消费的场景
        // autoDelete：是否自动删除  消费完删除
        // arguments：其他属性
        channel.queueDeclare(QUEUE_NAME, false, false, false, null);

        //消息内容
        String message = "simplest mode message";
        channel.basicPublish("", QUEUE_NAME, null, message.getBytes());
        System.out.println("[x]Sent '" + message + "'");

        //最后关闭通关和连接
        channel.close();
        connection.close();
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver {

    private final static String QUEUE_NAME = "simple_queue";

    public static void main(String[] args) throws IOException, InterruptedException, TimeoutException {
        // 获取连接
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });
    }
}

工作队列模式

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver1 {

    private final static String QUEUE_NAME = "queue_work";

    public static void main(String[] args) throws IOException, InterruptedException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        // 同一时刻服务器只会发送一条消息给消费者
        channel.basicQos(1);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });

    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver2 {

    private final static String QUEUE_NAME = "queue_work";

    public static void main(String[] args) throws IOException, InterruptedException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        // 同一时刻服务器只会发送一条消息给消费者
        channel.basicQos(1);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Sender {

    private final static String QUEUE_NAME = "queue_work";

    public static void main(String[] args) throws IOException, InterruptedException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        // 声明队列
        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        for (int i = 0; i < 100; i++) {
            String message = "work mode message" + i;
            channel.basicPublish("", QUEUE_NAME, null, message.getBytes());
            System.out.println("[x] Sent '" + message + "'");
            Thread.sleep(i * 10);
        }

        channel.close();
        connection.close();
    }
}

发布订阅模式

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

public class Receive1 {

    private static final String EXCHANGE_NAME = "logs";

    public static void main(String[] argv) throws Exception {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.exchangeDeclare(EXCHANGE_NAME, "fanout");
        String queueName = channel.queueDeclare().getQueue();
        channel.queueBind(queueName, EXCHANGE_NAME, "");

        System.out.println(" [*] Waiting for messages. To exit press CTRL+C");

        // 订阅消息的回调函数
        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" + message + "'");
        };

        // 消费者，有消息时触发订阅回调函数
        channel.basicConsume(queueName, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

public class Receive2 {

    private static final String EXCHANGE_NAME = "logs";

    public static void main(String[] argv) throws Exception {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.exchangeDeclare(EXCHANGE_NAME, "fanout");
        String queueName = channel.queueDeclare().getQueue();
        channel.queueBind(queueName, EXCHANGE_NAME, "");

        System.out.println(" [*] Waiting for messages. To exit press CTRL+C");

        // 订阅消息的回调函数
        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received2 '" + message + "'");
        };

        // 消费者，有消息时触发订阅回调函数
        channel.basicConsume(queueName, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;

public class Sender {

    private static final String EXCHANGE_NAME = "logs";

    public static void main(String[] argv) throws Exception {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.exchangeDeclare(EXCHANGE_NAME, "fanout");

        String message = "publish subscribe message";
        channel.basicPublish(EXCHANGE_NAME, "", null, message.getBytes("UTF-8"));
        System.out.println(" [x] Sent '" + message + "'");

        channel.close();
        connection.close();
    }
}

路由模式

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver1 {

    private final static String QUEUE_NAME = "queue_routing";
    private final static String EXCHANGE_NAME = "exchange_direct";

    public static void main(String[] args) throws IOException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        // 指定路由的key，接收key和key2
        channel.queueBind(QUEUE_NAME, EXCHANGE_NAME, "key");
        channel.queueBind(QUEUE_NAME, EXCHANGE_NAME, "key2");

        channel.basicQos(1);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver2 {

    private final static String QUEUE_NAME = "queue_routing2";
    private final static String EXCHANGE_NAME = "exchange_direct";

    public static void main(String[] args) throws IOException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        // 仅接收key2
        channel.queueBind(QUEUE_NAME, EXCHANGE_NAME, "key2");

        channel.basicQos(1);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Sender {

    private final static String EXCHANGE_NAME = "exchange_direct";
    private final static String EXCHANGE_TYPE = "direct";

    public static void main(String[] args) throws IOException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        // 交换机声明
        channel.exchangeDeclare(EXCHANGE_NAME, EXCHANGE_TYPE);

        // 只有routingKey相同的才会消费
        String message = "routing mode message";
        channel.basicPublish(EXCHANGE_NAME, "key2", null, message.getBytes());
        System.out.println("[x] Sent '" + message + "'");
//        channel.basicPublish(EXCHANGE_NAME, "key", null, message.getBytes());
//        System.out.println("[x] Sent '" + message + "'");

        channel.close();
        connection.close();
    }
}

主题模式

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver1 {

    private final static String QUEUE_NAME = "queue_topic";
    private final static String EXCHANGE_NAME = "exchange_topic";

    public static void main(String[] args) throws IOException, InterruptedException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        // 可以接收key.1
        channel.queueBind(QUEUE_NAME, EXCHANGE_NAME, "key.*");

        channel.basicQos(1);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.DeliverCallback;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Receiver2 {

    private final static String QUEUE_NAME = "queue_topic2";
    private final static String EXCHANGE_NAME = "exchange_topic";
    private final static String EXCHANGE_TYPE = "topic";

    public static void main(String[] args) throws IOException, InterruptedException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.queueDeclare(QUEUE_NAME, false, false, false, null);
        // *号代表单个单词，可以接收key.1
        channel.queueBind(QUEUE_NAME, EXCHANGE_NAME, "*.*");
        // #号代表多个单词，可以接收key.1.2
        channel.queueBind(QUEUE_NAME, EXCHANGE_NAME, "*.#");

        channel.basicQos(1);

        DeliverCallback deliverCallback = (consumerTag, delivery) -> {
            String message = new String(delivery.getBody(), "UTF-8");
            System.out.println(" [x] Received '" +
                    delivery.getEnvelope().getRoutingKey() + "':'" + message + "'");
        };
        channel.basicConsume(QUEUE_NAME, true, deliverCallback, consumerTag -> {
        });
    }
}

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Sender {

    private final static String EXCHANGE_NAME = "exchange_topic";
    private final static String EXCHANGE_TYPE = "topic";

    public static void main(String[] args) throws IOException, TimeoutException {
        ConnectionFactory factory = new ConnectionFactory();
        factory.setHost("localhost");
        factory.setPort(5672);
        Connection connection = factory.newConnection();
        Channel channel = connection.createChannel();

        channel.exchangeDeclare(EXCHANGE_NAME, EXCHANGE_TYPE);

        String message = "topics model message with key.1";
        channel.basicPublish(EXCHANGE_NAME, "key.1", null, message.getBytes());
        System.out.println("[x] Sent '" + message + "'");
        String message2 = "topics model message with key.1.2";
        channel.basicPublish(EXCHANGE_NAME, "key.1.2", null, message2.getBytes());
        System.out.println("[x] Sent '" + message2 + "'");

        channel.close();
        connection.close();
    }
}

四种交换机介绍

直连交换机（Direct exchange）：具有路由功能的交换机，绑定到此交换机的时候需要指定一个routing_key，交换机发送消息的时候需要routing_key，会将消息发送道对应的队列
扇形交换机（Fanout exchange）：广播消息到所有队列，没有任何处理，速度最快
主题交换机（Topic exchange）：在直连交换机基础上增加模式匹配，也就是对routing_key进行模式匹配，*代表一个单词，#代表多个单词
首部交换机（Headers exchange）：忽略routing_key，使用Headers信息（一个Hash的数据结构）进行匹配，优势在于可以有更多更灵活的匹配规则

总结

这么多种队列模式中都有其应用场景，大家可以根据应用场景示例中进行选择

参考

转载至：https://blog.csdn.net/qq_32828253/article/details/110450249

版权声明：
作者：Joe.Ye
链接：https://www.appblog.cn/index.php/2023/04/02/introduction-and-application-scenarios-of-7-queue-patterns-in-rabbitmq/
来源：APP全栈技术分享
文章版权归作者所有，未经允许请勿转载。

THE END

二维码

打赏

海报

RabbitMQ七种队列模式介绍与应用场景（通俗易懂）

七种模式介绍与应用场景简单模式（Hello World）做最简单的事情，一个生产者对应一个消费者，RabbitMQ相当于一个消息代理，负责将A的消息转发给B 应用场景……

Spring Cloud Zuul 路由自动刷新原理

<<上一篇

RocketMQ详解——RocketMQ的消息模式

下一篇>>

文章目录

关闭

搜索内容

RabbitMQ七种队列模式介绍与应用场景（通俗易懂）

七种模式介绍与应用场景

简单模式（Hello World）

工作队列模式（Work queues）

订阅模式（Publish/Subscribe）

路由模式（Routing）

主题模式（Topics）

远程过程调用（RPC）

发布者确认（Publisher Confirms）

代码演示

简单模式

工作队列模式

发布订阅模式

路由模式

主题模式

四种交换机介绍

总结

取消回复

共有 0 条评论

热门文章

最新评论
