基于Nacos实现Spring Cloud Gateway实现动态路由的方法

简介

主要介绍以Nacos为配置中心，实现Spring Cloud GateWay 实现动态路由的功能。Spring Cloud Gateway启动时候，就将路由配置和规则加载到内存里，无法做到不重启网关就可以动态的对应路由的配置和规则进行增加，修改和删除。通过Nacos的配置下发功能可以实现在不重启网关的情况下，实现动态路由。

集成

Spring Cloud GateWay集成

• spring-cloud-starter-gateway：路由转发、请求过滤（权限校验、限流以及监控等）
• spring-boot-starter-webflux：反应式Web框架
• spring-boot-starter-actuator：监控系统健康

<dependency>
  <groupId>org.springframework.cloud</groupId>
  <artifactId>spring-cloud-starter-gateway</artifactId>
</dependency>
<dependency>
  <groupId>org.springframework.boot</groupId>
  <artifactId>spring-boot-starter-webflux</artifactId>
</dependency>
<dependency>
  <groupId>org.springframework.boot</groupId>
  <artifactId>spring-boot-starter-actuator</artifactId>
</dependency>

Nacos集成

nacos-client：Nacos客户端

<dependency>
  <groupId>com.alibaba.nacos</groupId>
  <artifactId>nacos-client</artifactId>
</dependency>

动态路由

DynamicRouteServiceImpl:提供动态路由的基础方法，可通过获取bean操作该类的方法。该类提供新增路由、更新路由、删除路由，然后实现发布的功能。

@Service
public class DynamicRouteServiceImpl implements ApplicationEventPublisherAware {

  @Autowired
  private RouteDefinitionWriter routeDefinitionWriter;

  private ApplicationEventPublisher publisher;

  /**
   * 增加路由
   * @param definition
   * @return
   */
  public String add(RouteDefinition definition) {
    routeDefinitionWriter.save(Mono.just(definition)).subscribe();
    this.publisher.publishEvent(new RefreshRoutesEvent(this));
    return "success";
  }

  /**
   * 更新路由
   * @param definition
   * @return
   */
  public String update(RouteDefinition definition) {
    try {
      this.routeDefinitionWriter.delete(Mono.just(definition.getId()));
    } catch (Exception e) {
      return "update fail,not find route routeId: "+definition.getId();
    }
    try {
      routeDefinitionWriter.save(Mono.just(definition)).subscribe();
      this.publisher.publishEvent(new RefreshRoutesEvent(this));
      return "success";
    } catch (Exception e) {
      return "update route fail";
    }
  }

  /**
   * 删除路由
   * @param id
   * @return
   */
  public String delete(String id) {
    try {
      this.routeDefinitionWriter.delete(Mono.just(id)).subscribe();
      return "delete success";
    } catch (Exception e) {
      e.printStackTrace();
      return "delete fail";
    }
  }

  @Override
  public void setApplicationEventPublisher(ApplicationEventPublisher applicationEventPublisher) {
    this.publisher = applicationEventPublisher;
  }

}

RouteDefinition：提供路由实体类，主要有predicates匹配来自用户的请求，filters服务路由

@Validated
public class RouteDefinition {
    @NotEmpty
    private String id = UUID.randomUUID().toString();

    @NotEmpty
    @Valid
    private List<PredicateDefinition> predicates = new ArrayList<>();

    @Valid
    private List<FilterDefinition> filters = new ArrayList<>();

    @NotNull
    private URI uri;

    private int order = 0;

    public RouteDefinition() {}

    public RouteDefinition(String text) {
        int eqIdx = text.indexOf("=");
        if (eqIdx <= 0) {
            throw new ValidationException("Unable to parse RouteDefinition text '" + text + "'" +
                    ", must be of the form name=value");
        }

        setId(text.substring(0, eqIdx));

        String[] args = tokenizeToStringArray(text.substring(eqIdx+1), ",");

        setUri(URI.create(args[0]));

        for (int i=1; i < args.length; i++) {
            this.predicates.add(new PredicateDefinition(args[i]));
        }
    }

    public String getId() {
        return id;
    }

    public void setId(String id) {
        this.id = id;
    }

    public List<PredicateDefinition> getPredicates() {
        return predicates;
    }

    public void setPredicates(List<PredicateDefinition> predicates) {
        this.predicates = predicates;
    }

    public List<FilterDefinition> getFilters() {
        return filters;
    }

    public void setFilters(List<FilterDefinition> filters) {
        this.filters = filters;
    }

    public URI getUri() {
        return uri;
    }

    public void setUri(URI uri) {
        this.uri = uri;
    }

    public int getOrder() {
        return order;
    }

    public void setOrder(int order) {
        this.order = order;
    }

    @Override
    public boolean equals(Object o) {
        if (this == o) return true;
        if (o == null || getClass() != o.getClass()) return false;
        RouteDefinition routeDefinition = (RouteDefinition) o;
        return Objects.equals(id, routeDefinition.id) &&
                Objects.equals(predicates, routeDefinition.predicates) &&
                Objects.equals(order, routeDefinition.order) &&
                Objects.equals(uri, routeDefinition.uri);
    }

    @Override
    public int hashCode() {
        return Objects.hash(id, predicates, uri);
    }

    @Override
    public String toString() {
        return "RouteDefinition{" +
                "id='" + id + '\'' +
                ", predicates=" + predicates +
                ", filters=" + filters +
                ", uri=" + uri +
                ", order=" + order +
                '}';
    }
}

NacosGatewayProperties：自定义属性绑定值，可通过配置文件配置属性

@ConfigurationProperties(prefix="nacos", ignoreUnknownFields = true)
@Configuration
public class NacosGatewayProperties {

    private String address;

    private String dataId;

    private String groupId;

    private Long timeout;

    public String getAddress() {
        return address;
    }

    public void setAddress(String address) {
        this.address = address;
    }

    public String getDataId() {
        return dataId;
    }

    public void setDataId(String dataId) {
        this.dataId = dataId;
    }

    public String getGroupId() {
        return groupId;
    }

    public void setGroupId(String groupId) {
        this.groupId = groupId;
    }

    public Long getTimeout() {
        return timeout;
    }

    public void setTimeout(Long timeout) {
        this.timeout = timeout;
    }
}

DynamicRouteServiceImplByNacos：实现runner，通过nacos下发动态路由配置

@Slf4j
@Component
public class DynamicRouteServiceImplByNacos implements CommandLineRunner {

    @Autowired
    private DynamicRouteServiceImpl dynamicRouteService;

    @Autowired
    private NacosGatewayProperties nacosGatewayProperties;

    /**
     * 监听Nacos Server下发的动态路由配置
     * @param dataId
     * @param group
     */
    public void dynamicRouteByNacosListener() {
        try {
            ConfigService configService = NacosFactory.createConfigService(nacosGatewayProperties.getAddress());
            String content = configService.getConfig(nacosGatewayProperties.getDataId(), nacosGatewayProperties.getGroupId(), nacosGatewayProperties.getTimeout());
            log.info(content);
            configService.addListener(nacosGatewayProperties.getDataId(), nacosGatewayProperties.getGroupId(), new Listener() {
                @Override
                public void receiveConfigInfo(String configInfo) {
                    List<RouteDefinition> list = JsonUtils.toList(configInfo, RouteDefinition.class);
                    list.forEach(definition -> {
                        dynamicRouteService.update(definition);
                    });
                }

                @Override
                public Executor getExecutor() {
                    return null;
                }
            });
        } catch (NacosException e) {
            e.printStackTrace();
        }
    }

    @Override
    public void run(String... args) throws Exception {
        dynamicRouteByNacosListener();
    }
}

Nacos配置下发

Nacos配置

nacos:
  address: 127.0.0.1:8848
  data-id: ok-cloud-gateway-route
  group-id: dev
  timeout: 5000

Nacos属性文件定义

新建dataID为ok-cloud-gateway-route，groupID为dev的配置

[
  {
    "filters": [],
    "id": "blog",
    "order": 0,
    "predicates": [{
      "args": {
        "pattern": "/about"
      },
      "name": "Path"
    }],
    "uri": "https://www.appblog.cn"
  },
  {
    "filters": [],
    "id": "user-service",
    "order": 0,
    "predicates": [{
      "args": {
        "pattern": "/user/**"
      },
      "name": "Path"
    }],
    "uri": "lb://ok-cloud-user-service"
  }
]

查看路由信息：http://127.0.0.1:9000/actuator/gateway/routes
